User Selectable Levels: 3 main level (High, Medium and Low).
Each main level can be configured to one of its two sub-levels. The second
sub-level of the High can be further configured to different brightness levels
or strobes.
Light output are out the front (OTF) values. Runtime tests
are done using Sanyo 2000mAh Eneloop AA batteries.
The 123, 76, 27, 13 and 2.6 Lumen output levels are current regulated. The
60 and 0.28 Lumen output levels are PWM generated.
Operating Voltage Range: 0.7V - 2.5V
Battery: One 1.5V AA (NiMH, lithium or alkaline). 14500 Li-ion batteries
are not supported. Batteries are not included in the package.
Parasitic Drain: Negligible (equivalent to 16 years)
Beam Type
90° beam spread
Dimensions
Diameter: 0.90 inch (23 mm)
Length: 3.2 inch (81 mm)
Weight
1.2 oz (35.8 gram)
2.2 oz (61.9 gram) with an Eneloop AA
3.0 oz (84.9 gram) with an Eneloop
AA and headband
Features
Electronic soft-touch switch, with a 200,000 cycle operating life
Smart user interface provides fast and easy access to all brightness levels
Precision machined unibody casing from premium grade Alcoa aluminum bar
stock
Proprietary heat sinking design bonds the LED board directly to the unibody
aluminum casing, providing unblocked thermal paths to over 94% of the surface
area.
Durable natural hard anodized finish (Type III Class I)
Tempered optical grade ground glass
Orange peel textured reflector
Glow In The Dark (GITD) silicone ring near the tail cap
Battery power can be locked out by slightly unscrewing the tailcap to
prevent unwanted activations or parasitic drain
