| Overview |
|
 |
|
The Quark series offers a staggering array of options, accessories and interchangeability. With a wide range of LED, battery and clip choices, you get the features you want without compromise. Waterproof and constructed with aircraft-grade aluminum and impact-resistant lenses, Quark lights are tough enough to meet any challenge.
The QB2A features a larger, deeper reflector for improved throw! This subseries operates the same as the Tactical subseries: with a significantly different UI than the regular Quarks. This UI allows the user to program both primary and secondary outputs. |
|
| FEATURES |
|
・Current Regulation
・Smart Circuit for Rechargeable Batteries
・Reverse-Polarity Protection |
|
| Specifications |
|
| DIMENSIONS |
Length: 6.2 inches/Body diameter: 0.9 inches/
Head diameter: 1.2 inches/
Weight (without batteries): 3 oz |
|
| LED EMITTER |
CREE XP-G |
|
| VOLTAGE RANGE |
0.9V-4.2V |
|
| SPOT BEAM |
Angle: 9.5°/Diameter at 3mm: 500mm |
|
| FLOOD BEAM |
Angle: 59.1°/Diameter at 3mm: 3.4M |
|
| BRIGHTNESS LEVELS |
Moonlight: 0.2 lumens, 30 days, 1ma /
Low: 4 lumens, 5 days, 10ma /
Medium: 22 lumens, 24 hrs, 50ma /
High: 85 lumens, 5 hrs, 250ma /
Maximum: 205 lumens, 1.3 hrs, 700ma |
|
| SPECIAL MODES |
Strobe: 205 lumens, 2.5 hrs /
SOS / Beacon: 0-205 lumens pulse, 18 hrs |
|
| REFLECTOR |
Smooth |
|
| BODY MATERIAL |
Type-III hard-anodized aircraft-grade aluminum |
|
| BEZEL MATERIAL |
Type-III hard-anodized aircraft-grade aluminum |
|
| LENS MATERIAL |
Impact-resistant glass, sapphire coating, antireflective coating |
|
| NCLUDED ACCESSORIESI |
Batteries, lanyard, split ring for keychain attachment,
spare o-ring, holster, hand-grip |
|
|
